PERREAUX 80i INTEGRATED AMPLIFER

PERREAUX 80i INTEGRATED AMPLIFER

Regular price $5,895.00
Regular price Sale price $5,895.00
Sale Sold out
Tax included. Shipping calculated at checkout.

PURE, DISTORTION FREE HIGH PERFORMANCE INTEGRATED AMPLIFIER

Rugged, powerful, built to last a lifetime. The award-winning PERREAUX 80i integrated amplifier is an elegant, well-seasoned and reliable performer. Now in its tenth year of production the fully-featured 80i incorporates the precision ES SABRE ES9006 Reference Digital Audio Converter (DAC), PERREAUX Moving Magnet (MM) Phono Preamplifier Module with Earthing Terminal for Turntable connection, Line-level Analog (RCA) Inputs, Home Theatre Bypass, Preamp and Line Level Outputs, Serial and Full-function IR Remote Control and Backlit Touch Panel Controller.

The PERREAUX 80i Stereo Integrated amplifier delivers powerful, pure, distortion-free sound for the discerning music lover. Featuring the high-performance - USB Asynchronous 24 bit / 96k ES SABRE ES9006 Reference Digital Audio Converter (DAC) the 80i provides connection and control of multiple Digital and Analog audio Input sources including Unbalanced Analog Line Inputs 3 (RCA), USB, Optical 2 (Toslink) Digital and Coaxial (SPDIF) Digital Inputs. Unbalanced Preamp (RCA) and Unbalanced line (RCA) Outputs are provided for connection to additional audio power amplifiers such as the PERREAUX 100p , 350 or 750 power amplifiers for multiple speaker systems and external High Fidelity audio equipment. Additional features include an integrated, class-leading PERREAUX Moving Magnet Phono Module for Turntable connection, elegant backlit Touch Panel control, Serial and full-function IR Remote Control and Home Theatre bypass function for connection to Home Theatre Surround Sound Systems. Available in Anodised Silver / Black or hand-painted Midnight Black finishes. Optional Rack Mounting Kit also available - The PERREAUX 80i Integrated Amplifier - Order yours today!

SPECIFICATIONS

Amplifier Section Power Output:

80W into 8Ω 130W into 4Ω
Total Harmonic Distortion (THD+N):
Typically 20Hz to 20kHz
0.002% @ 1kHz <0.05%
Frequency Response:
Typically 20Hz to 20kHz
20Hz to 20kHz ±0.1dB, 20Hz to 20kHz
Signal to Noise (A-weighted):
105dB, ref. 80W into 8Ω
Damping Factor:
400 @ 1kHz, ref. 8Ω
Gain:
28dB

Preamplifier Section

Analogue Inputs:
3 Line Level (RCA) 1 Phono (RCA)
Home Theatre Input:
Yes (selectable)
Analogue Input Impedance:
47kΩ
Home Theatre Input:
Yes (selectable)
Volume Control Range:
-90.0dB to +6.0dB
Analogue Outputs:
1 Pre Out (RCA) 1 Line Out (RCA)
Analogue Output Impedance:
Pre Out: Line Out:
540Ω 270Ω
Signal to Noise Ratio (A-weighted):
113dB, ref. 2Vrms

Digital Audio Section

Digital Inputs:
1 USB (Asynchronous 24/96) 1 Coaxial (SPDIF) 2 Optical (Toslink)
Digital Input Impedance:
75Ω (Coaxial)
Transformer Coupled Digital Input:
Yes (Coaxial)
Digital to Analogue Converter:
ESS Technology Sabre Reference ES9006 DAC
Input Word Length (maximum):
24-bit (all inputs)
Input Sample Rate (maximum):
96kHz (all inputs)
Digital to Analogue Conversion:
24-bit/96kHz (upsampled)
DAC Output Voltage:
1.95Vrms @ 0dBFS
Total Harmonic Distortion (THD+N):
Typically 20Hz to 20kHz
0.002% @ 1kHz, -20dBFS <0.004%, -20dBFS
Frequency Response:
20Hz to 20kHz
±0.2dB
Signal to Noise Ratio (A-weighted):
120dB, ref. 0dBFS

Phono Module

Gain:
40dB
Input Impedance:
47kΩ
Input Capacitance:
100pF
Total Harmonic Distortion (THD+N):
Typically 20Hz to 20kHz
0.06% @ 1kHz, 1Vrms <0.15%, 1Vrms

General

Power Consumption
Standby: Idle: Maximum (130W into 4Ω):
<1W 50W 640W

Dimensions

Width:Depth:Height:
431mm (17.0") 309mm (12.2") 67mm (2.6")
Weight:
11.5kg (25.3lb)
